耳鉗 Ear forceps
友情提示： 為達到產品樣式最佳展現效果請切換電腦瀏覽器或手機橫平瀏覽！
 |
||||
 |
0°碗形口 |
E-015-HZ |
-D -Z -X |
|
 |
45°碗形口 |
E-016-HZ |
-D -Z -X |
|
● 小巧的頭部與纖細的頸部使視野更開闊
● Smaller head and slender neck widen the field of vision
● 頸部超大中空結構確保夾持更牢穩
● Super-large neck hollow structure ensures more firm clamping
● 后端間隙增加推力范圍實現更大的夾持力
● Increasing thrust range to achieve greater clamping force by backend clearance
● 高強度鋼提高了桿部的力量承受能力
● High Strength Steel Improves Strength Bearing Capacity of Rod
● PVD鍍膜使耐腐蝕、耐磨損、防反光得到了極大改善
● PVD coating greatly improves corrosion resistance, wear resistance and anti-reflective property.
產品參數 Product parameters
|
耳鉗 Ear forceps |
|||||||||
|
型號 |
規格 |
頭部 head |
總長 |
||||||
|
L |
W（內） |
W（外） |
H |
||||||
|
KRT-E-015 |
-HZ |
-D |
碗形口 |
0° |
Ø4mm |
Ø1.8mm |
Ø2mm |
Ø2mm |
85mm |
|
-Z |
Ø3.5mm |
Ø1.3mm |
Ø1.5mm |
Ø1.8mm |
|||||
|
-X |
Ø3.2mm |
Ø1mm |
Ø1.2mm |
Ø1.5mm |
|||||
|
KRT-E-016 |
-HZ |
-D |
碗形口 |
45° |
Ø4mm |
Ø1.8mm |
Ø2mm |
Ø2mm |
|
|
-Z |
Ø3.5mm |
Ø1.3mm |
Ø1.5mm |
Ø1.8mm |
|||||
|
-X |
Ø3.2mm |
Ø1mm |
Ø1.2mm |
Ø1.5mm |
|||||
